KEYFEATURES
● Digital meter, max current 200A
● 3.2 electrode continuously
● IGBT inverter technology
● Arc force & VRD adjustment
● Lift TIG function
● 35-50mm sockets
● Easy arc starting
● Downwards capacitance design for high dust proof level
● Auto-compensation for voltage fluctuation
● Over heat and over current self-production function
TECHNICAL DATA
Input Voltage | AC220V-50/60Hz |
Rated Input Power(KW) | 9.6 |
Rated Input Current(A) | 43.6 |
Current Range (A) | 30-200 |
Rated Output Voltage (V) | 28 |
No-load Loss(W) | 40 |
No-load Voltage(V) | 58 |
Duty Cycle(%) | 60 |
Protection/Insulation Grade | IP21S/F |
Packing Dimension(L*W*H mm) | 440x260x340 |
Net Weight (KG) | 6.5 |
STANDARD ACCESSORIES
