KEY FEATURES
High accuracy
Advanced digital logic circuit control
High production efficiency
Micro-computer controller
Fine tuning of welding current from 20% to 100%
Welding of low carbon steel, wire and stainless steel plate
Widely used in automobile, aviation, construction, machinery, metal products,electrical switch
TECHNICAL DATA
| Model | DN-10 | DN-25 | DN-35 |
| Input Voltage(V) | AC380V土15% | AC380V土15% | AC380V土15% |
| Frequency(HZ) | 50 | 50 | 50 |
| Rated Input Power(KW) | 10 | 25 | 35 |
| Rated Input Current(A) | 26.3 | 66 | 92 |
| Duty Cycle(%) | 10 | 10 | 10 |
| No-oad Voltage(V) | 1.65-2.4 | 2.3-3.55 | 2.6-4.2 |
| Control Series | 4 | 4 | 4 |
| Welding Time Range(S) | 0-5.99 | 0-5.99 | 0-5.99 |
| Machine Arm Length(MM) | 260 | 280 | 280 |
| Welding Thickness(MM) | 1.5+1.5 | 2.5+2.5 | 3.5+3.5 |
| Type Of Cooling | Transformer | Electrode:Water-cooling | Electrode:Water-cooling |
| Net Weight(KG) | 70 | 98 | 101 |
